Gold centrifugal concentrator is a type of gravity concentration equipment for concentrating gold, silver, tin, lead
Gold centrifugal concentrator is a type of gravity concentration equipment for concentrating gold, silver, tin, lead. centrifugal gold concentrator successfully separates the minerals under the high speed centrifugal rotation of the bowl as well as pressured fluidization water.
Centrifugal gold concentrator can be used not only for placer gold mining, but also for hard rock mining to recover the natural gold, replacing amalgamation. It is also used to recover gold from the old tailings.
In operation, material is fed as a slurry of minerals and water into a rotating bowl that includes special fluidized grooves or riffles to capture the heavies.
Fluidized water/back wash water/recoil water is introduced through the multiple fluidization holes in the inner cone to keep the bed with heavy minerals. Fluidized water/back wash water/recoil water plays an important role during the separation.
Periodically, heavy particles(big gravity heavy minerals such as gold,iron etc) are trapped in the grooves/riffles/gratings/ribs while the light particles(small gravity light fine minerals such as sand) are washed away upward into the tailings.
Technical Parameter
| Model No | HX-72 |
| Capacity(t/h) | 2-3 |
| Feeding Size(mm) | 0-3 |
| Feeding Density(%) | 10%-50% |
| Motor Power(kw) | 1.1 |
| Speed(rpm) | 190 |
| Dimension(mm) | 1000*1000*950 |
| Weight(kg) | 145 |
| Voltage | 380V/50Hz/Three phase |
